How to Check Transfer Case Fluid Level 2005-16 Toyota RAV4
Created on: 2019-09-23
Watch this video to learn how to check the transfer case fluid level on your 05-16 Toyota RAV4.
-
step 1 :Checking the Transfer Case Fluid Level
- Raise and support the vehicle
- Remove the 10 mm hex transfer case fill plug
- The fluid level should be at the base of the fill hole, with a slight drip
- Refer to the vehicle manual for the type of fluid if you need to top it off
- Reinstall and tighten the 10 mm hex fill plug
- Lower the vehicle
Tools needed
-
Jack Stands
Ratchet
Cloth Rags
Floor Jack
10mm Hex Socket
Brake Parts Cleaner
What's up guys? I'm Andy from 1A Auto. In this video I'm going to show you how to check the fluid level in your transfer case on this 2010 Toyota RAV4. If you need any parts for your vehicle, click the link in the description and head over to 1aauto.com.
So underneath the vehicle you want to make sure the vehicle is level while you're doing this. And in the front we're going to use a hex socket. It's a 10 millimeter hex socket, and a ratchet, and the fill plug is located right here. So basically in between the transfer case and the transmission or the engine area right there, loosen this up, it's on there pretty good.
I need a pipe, right. I actually need a pipe to add a little leverage. There we go. Once I get it started then I can take the socket off, or the ratchet off, because there's not a lot of room in here, so be careful. You don't want to get your ratchet stuck. So just break it free and then do it by hand. Pull that fill plug out, and the fluid level is right up to the base of the fill plug, which is good. That's where we want it to be.
And actually on this vehicle, it has a little sticker right here that tells you what kind of fluid to use, which is nice. So 85W-90 GL-five, so that's kind of nice. And then if you want, or if you have a gasket, you want to replace that fill plug gasket, or seal, and put the fill plug back in. All right, get the socket on, snug that up, not too tight. Then we'll take some brake parts cleaner, just clean it off. Then we just take a rag and wipe it away, and you're good to go.
Thank for watching. Visit 1aauto.com, your place for DIY auto repairs, for great parts, great service, and more content.
