How To Install Replace Rear Power Window Switch 2005-10 Volkwagen VW Jetta
Created on: 2015-01-26
How to repair, install, fix, change or replace a damaged, worn out, faulty or shorted power window switch on 05, 06, 07, 08, 09, 10 Volkswagen Jetta
-
step 1 :Removing the Door Panel
- Pry up the pull handle panel with a flat blade screwdriver
- Remove the two T30 Torx screws in the door pull
- Remove the T20 Torx screw on the bottom of the panel
- Pry out the door panel
- Lift the door panel up and off
- Disconnect the latch cables from the door handle
- Disconnect the door lock wiring harness
- Disconnect the window switch wiring harness
- Disconnect the speaker wiring lead
- Disconnect the courtesy light wiring harness
- Removing any remaining clips in the door with a pair of pliers
-
step 2 :Removing the Power Window Switch
- Remove the three T20 screws on the back of the pull handle
- Remove the pull handle
- Apply pressure to the switch and release the tabs on either side
- Remove the switch
-
step 3 :Installing the New Power Window Switch
- Push the pull handle into place
- Insert the three T20 screws on the back of the pull handle
- Insert the switch into the handle
-
step 4 :Reinstalling the Door Panel
- Connect the courtesy light wiring harness
- Connect the window switch wiring harness
- Connect the speaker wiring lead
- Connect the door lock wiring harness
- Connect the latch cables to the door handle
- Lift the door panel into place
- Push in the door panel clips
- Insert the T20 screw at the bottom of the door panel
- Insert the two T30 Torx screws in the door pull
- Push on the pull handle panel
Tools needed
-
Flat Blade Screwdriver
T20 Driver
T30 Driver
Needle nose pliers
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the rear power window switch on this 2005 Volkswagen Jetta. We'll show you on the driver side, but the passenger side is the same procedure. The items you'll need for this is a new power window switch from 1AAuto.com, T30 Torx bit and ratchet, flat blade screwdriver, and a T20 Torx driver.
Pry off the pull handle panel. Just pry from the bottom and pry from the center and it pulls free. Then remove these two T30 screws, and the one T20 screw at the bottom of the door. Once those are removed, pull out sharply on the door panel and it will release the clips. Then lift the door panel up and out of the window sill. Then pull the panel back. Unclip your door handle cable, slide it forward, and then unhook it. Push the tabs on the other side of this harness and pull it free. Push the tab on this harness and disconnect it. Up here is another two-tab harness. Now up here just push the tab on this harness and disconnect it. Then just disconnect this last harness right here. If you have any clips left behind just pull them out with some pliers and then slide them back into place on the door panel.
Remove these two T20 screws. We'll fast-forward as Mike does that. Then remove this T20 screw right here. Now, just pull the pull handle out. You may have to maneuver it a little bit, but it will pull free. There is a tab that tucks under here, it helps just to push that. Then, to remove the switch, there's two tabs on either side, so pry out the two tabs while applying pressure in the opposite direction. I'm going to do the same thing on the other side while pulling out on the switch and the switch will pull free.
Now you want to put the pull handle back into place, so just feed it back in place and then push this down and into that hole. We'll fast-forward as Mike replaces those screws. And then your switch just pushes right back into place.
Reconnect all of your harnesses for the door panel. Take your door handle cable and hook it back into the door handle and then slide the cable back and back into that clip. Once you've got it clipped in, take your door panel and tuck it back down into the window sill. Make sure the clips are lined up. Then hit them back into place. We'll fast forward as Mike replaces that one T20 screw and those two T30 screws. Take the pull handle panel, line it up, and push it back into place.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
