How to Replace Blower Motor Resistor 1996-2011 GMC Savana 1500 Van
Created on: 2013-09-17
Learn how to replace a bad or broken blower motor resistor on your 96-11 GMC Savana 1500 Van or Chevy Express with this helpful video.
-
step 1 :Removing the Blower Motor Resistor
- Disconnect the blower motor resistor wiring harnesses
- Unclip the wiring and pull it aside
- Remove the two 7/32 inch bolts from the blower motor resistor
- Pull out the blower motor resistor
-
step 2 :Installing the New Blower Motor Resistor
- Push the new blower motor resistor into place
- Insert the two 7/32 inch bolts into the blower motor resistor
- Clip the blower motor resistor wiring into place
- Connect the blower motor resistor wiring harnesses
Tools needed
-
Ratchet
7/32 Inch Socket
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the blower motor resistor in this 2005 GMC Savana, same as any 1996 to present Savana, as well as the Chevy Express. The blower motor resistor, when it goes bad, you'll start losing speeds on your blower. For example, you might have speed one and four, but not two and three. It's pretty easy. All you need is a 7/32 inch socket and a ratchet.
The first thing you want to do, is you can see there's a connector right here, and, as you follow these wires, there's another connector right back here. What you want to do, is you want to unplug both of those so just pry up on the tab, pull the connector out, and then, you want to do the same thing on the other connector. Just unhook the wires from that little hook, up top, there, and pull them down and set it aside. You can see there are two 7/32 inch bolts and we'll just fast forward as he removes those. Once the bolts are removed, you can just pull the resistor right out.
To install the new one, you just want to push the resistor down into place and replace those two 7/32 inch bolts. You can see, he just tightens them by hand, first, and then, using the socket and ratchet, he tightens them up. Now you just want to connect those connectors. Make sure you put the red and black wire back up on that hook, and the connectors just push right in and you're all set.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
