How to Replace Door Weatherstrip Seal 1999-2006 Chevy Silverado 1500
Created on: 2014-06-04
Watch this video to learn how to fix leaks or wind noise by replacing your weatherstripping. The experts at 1A Auto show how to replace the door seals on your 00-06 Chevy Suburban or Tahoe.
-
step 1 :Removing the Door Weatherstrip
- Pry off the door sill panel with a flat blade screwdriver
- Lift up the weatherstrip at the seam
- Pull the weatherstrip off, continuing around the door
-
step 2 :Installing the New Weatherstrip
- Push the new weatherstrip into the seam
- Pry back the door frame panel with a flat blade screwdriver and push the weatherstrip behind it
- Continue installing the weatherstrip around the door
- Pull back the ceiling handle to squeeze the weatherstrip behind it
- You will hear and feel the weatherstrip go in
- Continue installing the weatherstrip around the door
- Cut off any extra material with wire cutters
- Push the weatherstrip end into place
- Pry off any door sill panel clips that remained in the door frame with a flat blade screwdriver
- Push the clips into the door sill panel
- Push the panel into place
Tools needed
-
Flat Blade Screwdriver
Wire Cutters
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the rear door weather stripping on this 2002 Chevy Suburban. We show you on the passenger side, but the driver's side is the same procedure. The items you'll need for this are new weather stripping from 1aauto.com, a flat blade screwdriver, and wire cutters.
Using your flat blade screwdriver, pry up this panel and set it aside. Lift up the weather stripping at the seam and start pulling it out from around the door.
On the left, is the old weather stripping. On the right, is the new one from 1A Auto. You can see it's identical and it's going to fit exactly the same. Start pushing the weather stripping down around the seam and then use your flat blade screwdriver to pry back the panel while you tuck it in behind it. We'll fast forward as Don does this. When you get to this handle it gets a little more difficult. The handle's on there pretty good so what you have to do is pull back as far as you can on the handle, while pushing the weather stripping in underneath and just keep feeding it underneath until you get it to push in. When it does finally push in, you'll both feel and hear it go into place. Now that he's got it started we're going to fast forward as he does the rest of it and continue to fast forward as he goes down around the panel here and down to the bottom. You're going to have a little bit of extra most likely. Use some wire cutters to cut that extra off. Then push that end down into place.
Some of the clips from this panel may have stayed in here and the best way to remove them is to push them down through the slot and then push them out the other side. Set them aside and if they get bent just open them back up again with the flat blade screwdriver and then you want to push them onto these tabs. Once they're all back into place just push that panel back down and you're all set.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
