How to Replace Fog Light Assemblies 2011-17 Toyota Camry
Created on: 2019-02-20
How to install, repair, fix, change, or replace a broken, damaged, burned out, cracked, faded, cloudy or chipped fog light on 11, 12, 13, 14, 15, 16, 17 Toyota Camry
-
step 1 :Removing the Splash Shield
- Remove the 10mm bolts from the splashshield
- Lower the splashshield
-
step 2 :Removing the Fog Light Assembly
- Remove the Phillips screw from the fog light
- Remove the fog light
-
step 3 :Installing the Fog Light Assembly
- Insert the fog light assembly into place
- Tighten the Phillips screw to the fog light
-
step 4 :Installing the Splash Shield
- Insert the splash shield into place
- Tighten the 10mm bolts to the splash shield
Tools needed
-
Phillips Head Screwdriver
10mm Socket
Ratchet
Hi, I'm Mike from 1A Auto. We've been selling auto parts for over 30 years.
Hi, everyone. Sue here from 1A Auto, and today we have a 2013 Camry in the shop and I'm going to show you how to change the fog light assembly that is from 1A Auto. If you need this part or any other part for your car, click on the link below and head over to 1aauto.com.
So we're going to take the undercarriage splash shield down that's attached to the bumper with a 10 millimeter socket. We're just going to go from one side. Walk our way over to the other.
To remove the fog light, now we can put our hand up in here in the Phillips screw, that one mounting screw. I'm using a stubby screwdriver. And you back that screw out. Then you grab the new fog light and pull it towards you this way under the hinge part. Layer it out.
Here we have our brand new fog light assembly from 1A Auto. This is for a '13 Camry and here's the factory one we just took out of the bumper. You can see they have the same four mounting spots. Turn ours around. It comes with an adjuster, just like that one, and we also supply the bulb. And a vent for any moisture to come out. If you need this part or any other part for your car, click on the link below and head over to 1aauto.com.
Now we're going to put the new fog light up in. Pull down a little bit and just screw it underneath. You're going to put those two tabs in on the inner edge. Line those up. You're going to take these two tabs and line up with these two holes, eyelet holes, and just fog light right up in place. Now I'm going to put the Phillips screw back in the mounting hole. Snug that right in. Put the shield part up underneath the bumper cover and line up the actual mounting screws all the way around.
Thanks for watching. Visit us at 1aauto.com for quality auto parts, fast and free shipping, and the best customer service in the industry.
