How To Replace Fog Light Bulb 1998-2006 Suzuki XL-7
Created on: 2014-02-14
How to install, repair, fix, change or replace a broken, damaged, burned out, cracked, faded, cloudy or chipped fog light on Suzuki XL-7, years 01, 02, 03, 04, 05, and 06.
-
step 1 :Removing the Fog Light
- Remove the two clips in the wheel well with a flat blade screwdriver
- Pull back the inner fender and remove the three Phillips screws from the fog light
- Remove the fog light cover
- Disconnect the fog light wiring harness
- Remove the Phillips screw in the fog light
- Remove the fog light bulb
-
step 2 :Installing the Fog Light
- Insert the fog light bulb into place
- Insert the Phillips screw in the fog light
- Connect the fog light wiring harness
- Push on the fog light cover
- Insert the three Phillips screws to the fog light cover
- Push on the two clips in the wheel well
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and the next time you need a part for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the fog light bulb on this 2002 Suzuki XL-7. We show you on the passenger side, but the driver side is the same procedure. The only tools you'll need for this is a flat blade screwdriver and a Phillips screwdriver.
You want to start off by removing this clip here and this clip right here. To do that, use your flat blade screwdriver to pry out the center and then pull the clip out. Pull back that inner fender and then remove these two Phillips screws from the back of the fog light. We'll fast-forward as Don does this. Pull that cover down and then disconnect this harness. Remove this Phillips screw right here. Once that's removed the fog light bulb will pull right out.
Your new fog light bulb, feed it up into place and line up the hole for the Phillips screw. Put that wire back into place and then replace the screw. We'll just fast-forward as Don tightens that up. Reconnect the wire harness and put the cover back into place. We'll fast-forward as Don replaces those two Phillips screws. Replace the inner fender and those two clips. You're all set.
