In this video, we're going to show you how to replace the door glass in this 2017 Ford F-150. We show you with the glass not broken, obviously. If your glass got broken, it'd be a little bit different. You just want to make sure you clean out all broken glass, and be careful.

Hope you like this video. Please click subscribe. Also, for all your parts needs, check out the link in the description to 1AAuto.com. We have thousands of parts, for many makes and models.

Here are the items you'll need for this repair.

Open up the door. And if you have a switch to turn off your dome light, shut off your dome light so that you don't drain your battery. Remove this panel, and you can pull out on it, and get your fingers underneath. The right tool is a plastic tool, get under here to help you pry it a little bit. If you had to, you could also use a screwdriver—just wrap it in a rag so you don't scratch your paint. But you just want to remove this panel. Pull straight out on it. When you get the top released, work your way down to the bottom. And again, pull straight out, don't pull down, you don't want to break anything.

Next, you want to pull this panel off. There's a little indent where you can work a tool, or a screw driver in. This panel is held in very tightly, so there's actually an indent here. I'm going to use a screwdriver, because you need something metal that doesn't flex. Work the screwdriver way up in there. And I'm going to try and hold the panel with my thumb, or else it's going to go flying. Now, pull out this panel. You want to pry from the top.

There are seven 7mm screws that hold it in: two, three, four, five, and then way down at the bottom here, six, and seven. Use a 7mm socket ratchet and extension to remove them. And these lower ones are at quite a bit of an angle. And then there's clips in the back to release. I like to start right up here. Firm pull. Then work your hand down. Firm pull. And the panel comes off.

And disconnect your window switch, and your power door lock switch. Little tab, push and pull down. Disconnect the door handle. Very easy, kind of apply some pressure, just pull down on this tab. It comes right out.

Four seven millimeter bolts hold the speaker in place. Remove those. Last one comes out. Little tab on your harness, here. Push down. Disconnect the speaker, then you'll pull the bottom out first. The speaker comes off. Carefully peel your water shield from the door. You want to try and leave all the stuff either on the door, or on the shield, itself. Peel it down so you can see in there well. We're going to reconnect the window switch. You remove it from the door panel, either using trim tools, or if your door panel's off, you just push it up from the bottom, and reconnect it, to move your window up and down.

Take your window. Raise it up. You may want to have somebody help you do this, but there are two tabs that you'll want to position so you can get to them. The position of the window's going to be right about there. We'll show you those two tabs. Remove this window channel.

It's easy enough to see this one. Just take a screwdriver, push on that tab, and then lift your window up out of the regulator. Just like on the front, the best way to get through it is just through this access hole. Just position the window perfectly so you can get in there. Push it with a screwdriver. Unlock the back of the window, and then go to the front. Unlock the front of the window. You can push the window up. Once you have it disconnected, push your regulator things down. Let the window go down. Tilt it forward. That could have been a little bit further. Tilt it forward. Then, you can pull the window up and out.

Put the nose down in first. Then make sure you're going to the outside of the regulator. Make sure you have the window properly in the rear channel. You can slide it right down into your regulator, and it snaps in place. Put this seal back in place. This sweep's right against the glass. Turn your key on. Run your window up and down a few times. Make sure nothing's binding. Make sure it all works properly.

Reinstall your speaker. Put the top in first. Then, those two pins go in. Then, use your four seven millimeter screws and install. Tighten these up. You want to get them firm, but not too tight. Don't overtighten them. Reconnect your lead. Just something to keep in mind. There's a large alignment pin here that goes into this hole in the front, here.

Reconnect your window switch first. Then your door lock. Then bring your door handle up. The largest alignment pins in the front, there's a large hole in the door, put your panel up. Get your lock through, and then you need to push the top of the panel, pull the bottom out, push the top of the panel down on until that alignment tab goes in. Then you can look right back in here, and you'll see a tab here, go down until that tabs in place. Then pretty much everything should line right up.

Activate all the clips. Ones with the large washers, go right where you door pull is. Silver ones with the smaller washers, go down underneath the door handle, or the door pull. And then the black ones: one goes up at the top, and the other two go at the bottom. These are all 7 mm, and we'll tighten them up. Put in the bottom cover first. There's tabs that go at the bottom, and then the locking clips are up top. Then this one cap, goes into the back. Line it up, goes on easy enough. And then the mirror cover.
