How to Replace Ignition Lock Cylinder 1993-97 Dodge Intrepid
Created on: 2011-09-15
If the ignition lock cylinder needs to be replaced, this video will show how to remove the steering column to remove and install it yourself
-
step 1 :Disconnect the battery
- Use your 10 mm wrench to disconnect the negative battery terminal.
-
step 2 :Remove the steering column cover to access the ignition cylinder
- Start with the T30 Torx screw on the tilt lever.
- Remove the six T15 torx screws underneath the steering column.
- Pull the steering column cover off and set aside.
-
step 3 :Remove the ignition lock cylinder
- Put the key in and turn it to the run position.
- Depress the little square button to pull the key cylinder out.
-
step 4 :Install the new lock cylinder from 1A Auto.
- Put the O ring onto the lock cylinder.
- Depress the button and put the key into the cylinder.
- Put the cylinder into place and make sure the little button clicks in to secure it.
- Replace the steering column cover and secure with the T15 screws.
- Screw the T30 screw back in to secure the tilt lever.
Tools needed
-
T15 Torx Driver
T30 Driver
10mm Wrench
Brought to you by 1AAuto.com. Your source for quality replacement parts and the best service on the internet. Hi, I'm Mike Green, one of the owners of 1AAuto. I want to help you save time and money repairing and maintaining your vehicle. I'm going to use my twenty plus years of experience restoring and repairing cars and trucks like this to show you the correct way to install parts from 1AAuto.com. The right parts installed correctly. That's going to save you time and money. Thank you and enjoy the video.
In this video we are going to replace the ignition lock cylinder and key on this 97 Intrepid. The only tools you'll need are T30 and T15 Torx drivers. If you replace this, you will need to keep the new key that comes with the ignition lock cylinder as well as your old key to work the doors. Take a 10mm wrench and disconnect your battery cable. To remove this, first thing, T30 Torx bit. Up underneath here, there's a screw to remove the tilt lever. Up and underneath, there is, I see two T15 screws there, another one there. There's one way up in that hole there. Way up in that hole there and then way up in that hole there. You're going to tilt. While were going, you can kind of reach in there with your finger and pull and still tilt. Make sure it's tilted all the way up.
We'll fast forward as I just I remove those six T15 Torx screws. You can see the silver ones that are at the bottom are shorter and the others you have to reach up into the holes or the cavities are longer screws. On the bottom one you kind of pull down and out. Over the key cylinder reach in, lift down and this one comes up and out. Once you have all the trim off, go right underneath the lock cylinder here and there's a little square button right there. That's where you put the key in. you want to turn it to the run position. Okay. Flip that button. Shoot up with your Torx driver and pull it right out. This is a lock from 1AAuto. I just want to make sure this O ring kind of slid down. The O ring belongs right into that groove there. Make sure you have your button down. Close it down.
Place our top panel down in first. Put it back up. I'm putting the bottom panel in. We're going to start the small bottom screws first. I'm not going to make you watch me put all those screws in in real time. Well fast forward it here. You start the bottom screws. Leave them kind of loose so you can move things around a little bit. Get the top in place. Start those three longer screws. Once you have them started, go back around and tighten them up. You tighten them they need to be tightened lightly. You want to make sure you don't strip any of the plastic or anything like that. Okay. Once you've done that, put the tilt lever back on and reconnect your battery. Reconnect the battery cable.
We hope this helps you out. Brought to you by www.1AAuto.com. Your source for quality replacement parts and the best service on the internet. Please feel to call us toll free 888-844-3393. Were the company that's here for you on the internet and in person.
