How to Replace Mass Air Flow Sensor 2006-09 Chevy Impala
Created on: 2013-08-28
Watch this video on how to replace the mass airflow sensor on your 06-09 Chevy Impala.
-
step 1 :Removing the Air Box Cover
- Undo the two air box clips
- Pull up the air box cover
- Loosen the hose clamp from the Mass Air Flow (MAF) Sensor with a flat blade screwdriver
- Disconnect the MAF sensor wiring harness
- Separate the hose from the air box
- Pull off the air box cover
-
step 2 :Separating the MAF Sensor from the Air Box Cover
- Remove the two T30 Torx screws from the MAF sensor
- Pull the MAF sensor from the air box cover
-
step 3 :Installing the new MAF Sensor
- Line up the air box cover peg with the MAF sensor hole
- Push the MAF sensor into place
- Insert the two T30 screws into the MAF Sensor
-
step 4 :Reinstalling the Air Box Cover
- Push the air box cover into place using the locating tabs
- Clip on the air box cover
- Push the hose onto the MAF sensor
- Tighten the hose clamps with a flat blade screwdriver
- Connect the MAF sensor wiring harness
Tools needed
-
Flat Blade Screwdriver
T30 Driver
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the mass airflow sensor on a 2006 Chevy Impala, fundamentally the same for model years 2006 through 2008. You'll need a Torx 30 bit and a socket wrench as well as a new mass air flow sensor from 1A Auto.
The mass air flow sensor is located on the air box on the driver side. You'll need to unclip the two clips that hold the air box cover in place. Then give it a good tug up because there are two tabs that sit into the bottom of the other part of the housing. Locate the screw clamp on the mass air flow sensor. I'm using a flat head screw driver to loosen up on that clamp. Your clamp might be different if it's been replaced or what not over the course of the years of the car. It's probably going to be a stainless steel screw clamp, but it might have a different head. Go ahead and disconnect by pressing in the tab on your mass air flow sensor and then remove the rubber portion of the hose and pull your mass airflow housing out.
There are two Torx 30 screws that hold the mass airflow sensor to the housing cover. Go ahead and fast forward as I remove or unscrew those and ultimately take them out. Once you've got your two screws out you can go ahead and remove the mass air flow sensor from the air box housing cover.
Going back in, you'll notice that it's notched. There's a peg on the air box cover and a hole in the mass airflow sensor. Those are going to line up so you can only put it in one way. Then go ahead and press it in firmly and reinstall your two Torx 30 screws. We'll go ahead and fast forward as I do that.
Going back in, you'll notice the two tabs on the bottom of that housing cover. They're going to go into corresponding holes in the other part of the air box right there, so you're going to want to make sure that those slide in before you clamp it and make sure that you're not pinching any of the wires. I'll go ahead and fast forward as I do that. Now secure the two clips. Go ahead and reinstall the rubber hose that goes to the mass air flow sensor and use a screw driver and tighten down on your hose clamp. Then once you've done that, don't forget to plug in your mass air flow sensor.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
