How to Replace Overhead Center Console 2014-19 Chevy Silverado
Created on: 2019-05-03
Check out this video from 1A Auto to learn how to remove or replace the overhead center console of your 14-19 Chevy Silverado if it is damaged or loose.
-
step 1 :Removing the Overhead Center Console
- Tip the glasses holder slightly to access the edge of the center panel
- Pry the center panel out
- Remove the two electrical connectors
- Remove the two T10 Torx screws
- Pull the center console straight out
- Disconnect the electrical connector
-
step 2 :Installing the Center Console
- Reconnect the electrical connector
- Push the center console straight in to lock it in place
- Replace the two T10 Torx screws
- Reconnect the two electrical connectors
- Press the center panel straight in to lock it into place
Tools needed
-
T10 Torx Driver
Socket Extensions
Flat Blade Screwdriver
Ratchet
What's up, guys? I'm Andy from 1A Auto. In this video I'm going to show you how to replace the overhead console on this 2015 Chevy Silverado. If you need parts for your vehicle, click the link in the description and head over to 1aauto.com.
To remove this center console, I'm going to just tip this glasses. Hold her down a little bit. I'm just going to use a pocket screwdriver to get in under here. There's a couple of locks to release. Once you get two of those, you can grab it and just pull it down. See, there's the retainers that hold it in. Just disconnect these connectors in here and I'll just use the pocket screwdriver for this one. Release that lock. Slide it out.
I'm going to remove these two screws: one here and one here. I'm going to use a T10 extension and a ratchet. I'm just going to grab here and here and pull this down just like that. To release this lock right here, there's two little fingers right there. You need to push on those fingers, squeeze them together, and release that. Slide it out.
I want to plug this back in. This is going to go, yep. This is going to go plugged in right here. Lock that in place. Line this up. There's some push tabs in the front. You can lock that in. You need two fasteners--two little screws. I'm going to use a T10 and an extension. I'm going to go right here. The other one is going to go on the other side, right there. Just take a ratchet and just snug them up. It is in plastic so don't over-tighten them. Just snug. We have this little cover. I'm going to plug this in, right there, and then plug this one in right here. Slide this cover up. Lock it in place.
Thanks for watching. If you want the parts to do it yourself, check out 1aauto.com, the place for DIY auto repair.
