How To Replace PCV Valve 1999-2006 GMC Sierra 2500 HD
Created on: 2013-04-24
If the PCV valve is failing, find out how to replace it with this video
-
step 1 :Removing the Engine Cover
- Remove the 8mm bolt from the engine cover
- Pull off the engine cover
-
step 2 :Removing the PCV Valve
- Pull up the PCV hose
- Pull the PCV valve out of the hose
-
step 3 :Installing the PCV Valve
- Push the PCV valve into the hose
- Push the PCV hose into place
-
step 4 :Reinstalling the Engine Cover
- Put the engine cover into place
- Insert the 8mm bolt into the engine cover
Tools needed
-
8mm Socket
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, I'm going to show you how to replace the PCV valve in this 2002 GMC 2500 that has a 6 liter. The 6 liters had the PCV valve removable and replaceable up through 2002, I believe. Also it's the same for a lot of the 5.3 liters, and really no tools are necessary. I do take the top engine cover off, but that is optional. It's pretty easy to replace.
With an 8mm socket, and ratchet, we're going to remove this top bolt.
If you lift up, these hoses aren't very flexible. There's a thicker looking hose that runs down here, and we'll just grab this hose, and pull it up. There's your PCV valve.
I think a new one goes on easy enough. Put this underneath, and right down and back in.
As I put that bolt back in, you probably can do this without taking that cover off, but I wanted to take the cover because I wanted to pull the hose up and show you the PCV valve. If you don't pull it up like that, most likely you can just do it without taking that cover off.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
