How to Replace Side Rear View Mirror 2003-07 GMC Savana
Created on: 2013-09-24
How to replace the side view mirror assembly. We stock these mirrors and many more parts you may need at 1AAuto.com to the Chevy Express or GMC Savana, model years 2002-2013.
-
Removing power windows requires removing the door panel. Removing manual windows does not.
step 1 :Removing the Door Panel
- Remove the door panel if you have power mirrors
- If you have manual mirrors, proceed to Step 2
- Pry off the door pull trim piece with a flat blade screwdriver
- Remove the six Phillips head screws inside the door pull
- Pry off the door panel bezel with a flat blade screwdriver
- Remove the two Phillips head screws inside the door handle
- Pry off the switch panel by hand
- Disconnect the door lock wiring harness
- Disconnect the window switch wiring harnesses
- Disconnect the mirror switch wiring harness
- Pry off the mirror base trim piece by hand
- Pry out the door panel by hand
- Lift the door panel up and off
-
step 2 :Removing the Mirror
- Pull off the mirror base trim piece if you have not already done so
- Remove the three 10mm nuts from the mirror
- Pull the mirror off
-
step 3 :Installing the Mirror
- Put the mirror into place
- Fasten the three 10mm nuts onto the mirror
- Continue to Step 4 if you have removed the door panel
- Otherwise, push on the mirror base trim piece
-
step 4 :Reinstalling the Door Panel
- Lift the door panel into place
- Push in the door panel clips
- Connect the door lock wiring harness
- Connect the mirror switch wiring harness
- Connect the window switch wiring harnesses
- Push the switch panel into place
- Insert the two Phillips head screws inside the door handle
- Push on the door handle bezel
- Push on the mirror base trim piece
- Insert the six Phillips head screws inside the door pull
- Push on the door pull trim piece
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
10mm Socket
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace a side view mirror on this 2005 GMC Savana. We show you the driver's side. The passenger's side is the same procedure. It's pretty much the same for most GMC Savanas and Chevy Expresses. This truck has manual mirrors so we didn't need to remove the door panel. Many trucks may have power mirrors and in the case of power mirrors, you'll need to remove the door panel to unplug the mirror harness inside the door. What we do is the first part of the video we just show you the simple take off and reinstallation of the mirror and then the second part of the video we show you how to remove the door panel and reinstall it.
Up in the top corner there will be a trim panel, just pull firmly from the bottom and the top. Then there are three 10mm nuts, there's two there and one further inside. I'll speed up here as we remove those three 10mm nuts. Then you can remove your mirror or what's left of your mirror.
Here you can see the new mirror from 1A Auto is the exact same as the old mirror. The truck has the little visors on the outside so Don just puts the mirror up underneath them and installs it. Now I'll just fast forward as he puts those three 10mm nuts on and tightens them up. Again this was the simple version, non-power mirror. Next you're going to see how to remove and reinstall your door panel and you'll need to do that if you have a power mirror that you have to disconnect inside the door.
Start by using a flat blade screwdriver and you can pry out on the outer panel of the door pull. You see there are clips that hold it in; they just pull right out. Now you can remove the inner panel by removing six screws: three small ones there, a larger one there and another small one there and a larger one there. We're just going to fast forward as we remove all of those screws.
Use a flat blade screwdriver again and pry on the panel that's right behind the door handle and that comes out. In behind there, there are two more Phillips screws. We'll fast forward here again as we remove those two screws and you do have to push in quite hard to keep the screwdriver in the screw to get it started. Now you can pull on that upper panel, and it unclips from the door panel, and then unclip all of your accessories in the back: power door locks, power windows, power mirror, et cetera. Usually they just have a tab that you press and pull the connector off.
Grab hold of that top mirror bezel and trim and pull firmly to remove it. Start at the top corner of the door panel, pull firmly and they're just a series of clips around the outer edge of the door panel that hold it into the door. You work your hand to each clip and pull firmly and they release and then you can lift the door panel up and off.
Installing the door panel is a reverse of the procedure. There are clips on the panel that go around the outside, so you want to first make sure that all your harnesses come through, hang the door panel up and make sure it goes down on the ledge of the window ledge and then just set the clips by using the back of your fist or your palm.
Speed things up here a little bit here. Take your accessory panel and make sure you clip all our accessories in place, power door locks, windows, mirror and then line it up on the door and clip it into place. Replace the two Phillips screws that are in behind the door handle and then put the trim bezel back on and clip it into place. Put the upper trim panel back in place just by putting the tab in at the bottom and pressing it in.
We'll speed up here again as we put the bracket in place that is the door pull and then holds the other piece of outer trim. If you're just taking the door panel on and off, you probably don't need to remove all those small screws, you probably just needed to remove the two big ones but this is the way we did it this time. We're putting those large screws back in place and then put all the other small screws put in place to hold it all together. Last but not least, snap that upper panel back in place.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
