How to Replace Tail Lights 1999-2007 Ford F250 Super Duty
Created on: 2011-11-11
Check out this video to learn how to replace the tail lights and bulbs on your 99-07 Ford Super Duty F250 and F350. 1A Auto shows you step by step.
-
step 1 :Removing the Taillight Assembly
- Remove the two 8mm bolts on the side of the taillight.
- Pull the taillight down and out.
- Twist the sockets out.
-
step 2 :Replacing the Bulbs
- Pull the bulb out.
- Push the new bulb into place.
-
step 3 :Replacing the Taillight Assembly
- Twist the sockets into the new taillight assembly.
- Line up the taillight and push it into place.
- Replace the two 8mm bolts on the side of the taillight.
Tools needed
-
8mm Socket
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the internet.
In this video we're going to show you how to remove and reinstall the taillight, whether you need to replace a broken taillight or you're just looking to replace a bulb. We're working here on a 2003 F250, same as any super duty truck of this era. The only tool you'll need is an 8mm wrench or socket with ratchet.
Okay, pretty straight forward. On the backside here there's two bolts that you need to remove. These bolts are 8mm. Speed it up here as I use an 8mm socket with a ratchet to remove those two bolts. Okay, once you have those bolts out pull down. The bulbs twist counterclockwise to disconnect. To service the bulb just pull it out, push it back in. The same up here. The new taillight from 1A Auto, if your taillight loses a battle with a 2x4 or fire wood, which happens on my truck a lot get a nice new light from 1A Auto. It goes right in. Everything goes right together. There are a couple line-up tabs. You just kind of want to get the bulbs in. Watch those line-up tabs. Get them in place.
Okay, we'll speed it up here as I put those two 8mm bolts back in. When you tighten them up you don't want to over tighten them, because you are just tightening speed screws into plastic, so make them firm but not too tight.
We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the internet. Please feel free to call us toll free, 888-844-3393. We're the company that's here for you on the internet and in person.
