How to Replace Timing Cover 1996-2000 V8 5-7l GMC K1500

Hi, I'm Mike from 1AAuto. We've been selling auto parts for over 30 years! We're dedicated to delivering quality auto parts, expert customer service, and fast and free shipping, all backed by our 100% satisfaction guarantee. So visit us at 1AAuto.com, your trusted source for quality auto parts.

In this video we're going to be working with our 1996 GMC Sierra K1500 5.7 liter V8. We're going to show you how to remove and replace your vehicles timing chain cover. This part is one time use so if it's leaking and you're removing it to reseal it, you will need to put a new cover on.

If you like this video, please click subscribe. We have a ton more information on this and many other vehicles and if you need this part for your truck, you can follow the link down in the description over to 1AAuto.com.

Here are the items you'll need for this repair: full metric socket set, 3/8 ratchet, socket extensions, small flat blade screwdriver, adjustable wrench, hammer, torque wrench, impact gun, drain bucket, brake cleaner, paper towels, razor, coolant, funnel, harmonic balancer puller, oil gasket sealer, pliers

Using a small flat blade screwdriver, pop open the wire retainer on the top of your fan shroud, lift the wire off, and it's long enough that you can just lay it back in the engine bay. You can remove it from the battery, and take it out completely, if you'd like to, but this should give you plenty of room to work.

Remove the seven 10 millimeter bolts along the fan shroud. There should be two on the bottom on each side. Ours is missing two bolts, and then three along the top, and the same two bolt locations on this side. We'll remove these with a 10 millimeter socket ratchet and extension. Once the hardware is removed, lift up, and remove the upper fan shroud from the vehicle.

Remove your radiator cap by pushing down and turning it counterclockwise. At the bottom of the driver's side of the radiator, you'll see a little thumb screw for your radiator drain. Make sure you have a drain bucket underneath there, then reach down and loosen it by hand. Allow your cooling system to drain and then close the drain on the radiator.

We're going to use an adjustable wrench, because we don't have the right size open-end wrench, but that would work as well. As well as, some pipe wrenches. We're going to place that over the clutch fan nut, and then strike it quickly with a hammer.

Using the drive of a three-eighths ratchet – you could also use a three-eighths breaker bar –, go into the slot on the serpentine belt tensioner, and rotate it as far as we can clockwise, to put some extra tension on the serpentine belt. Then, try hitting the wrench again because this should keep the pulley from turning. Once it's loose, you can remove your ratchet, spin the clutch fan off.

Now use a 3/8 drive ratchet to turn the tensioner counter clockwise and remove our serpentine belt. Make sure you have a belt path for this, either under the hood somewhere, take a picture, or draw one yourself.

Using a pair of locking jaw or other pliers, compress the clamp, move it off the end of the fitting for the water pump hose and then clamp on there. Twist it a little bit to free it up. Remove that from the water pump. Now, the other one is pretty tricky to get at, so we'll do the bottom hose on our water pump the same way. Remove the bolts and pull it out a little bit before, removing the other hose. Once again, we'll grab the hose with a pair of pliers. Just try to wiggle it, free it up a little bit. Once it's freed up, we'll remove the hose. Make sure there's a drain bucket underneath there.

Remove the four 14 millimeter bolts around the water pump with your 14 millimeter socket, ratchet, and extension. Now, normally the old gaskets tend to bake these on pretty good, so when you remove the bolts it should stay in place as long as you don't bump it. You can then wiggle the pump, pull it out far enough that we can access the last clip here. Remove that hose the same way we did with the first one using our pair of locking jaw pliers. Once everything's off you can remove your water pump from the vehicle.

Remove the three 14 millimeter crank pulley bolts. Now these tend to be pretty stuck on there, so you may need to use a strap wrench or something to hold the crank in place, but I found that if you crack them all loose before you remove any of them fully, and you kind of give them a little shock with the ratchet by just giving them a quick little jerk, sometimes you can free them up without needing to remove anything. Once you've cracked all the bolts loose, you can remove them fully.

Now use the 16 millimeter socket, ratchet, and extension to try to break loose the center bolt on the balancer. However, this is really torqued on there, so you may need to use an impact gun or some type of holder to get it off. Now you may be able to use a strap wrench, some kind of holder. If you have a manual transmission, you may be able to just lock it in place, but for us, the easiest method is going to be to break it loose with an impact gun. You can then remove the bolt and pulley from the harmonic balancer.

So now we'll reinstall the center bolt without the washer as far as we can by hand. We'll now use our harmonic balancer tool from 1A Auto, some of the supplied hardware fits the balancer bolt holes, so we'll set those in. You want to make sure these are all in equal lengths, so that it pulls straight and flat. Run in the center bolt, also supplied in our puller kit from 1A Auto.

We'll now use a 19mm socket and ratchet to tighten down the center bolt. Once we've tightened down the center bolt far enough, we can slide our harmonic balancer off by hand. Be sure to remove the center crank bolt.

Disconnect the crank position sensor and undo the eight millimeter bolt on the bottom with an eight millimeter socket and ratchet. You can then work the crank position sensor out of the bottom of the timing cover and remove it. You can now remove the eight 10 millimeter bolts around the perimeter of the timing cover. We'll do this using the 10 millimeter socket, ratchet and extension. You can now remove the timing cover from the front of the engine. You may need a screwdriver another small pry tool to help free the cover from the front of the motor.

We'll take a second to wipe off some of the heavy grease that's built up around our timing cover with a paper towel or rag. This is not to clean the gasket surface just yet, but it is because there's just so much debris around here from other leaking gaskets that it'll be hard to get a good clean on there anyway. Using a razor blade, scrape down any built up gasket material that may be on the main surface here. Our old cover did not have any sealant on it, so there's really not much to scrape off. It doesn't hurt to take a second and do this step anyway. This will also let you feel if there are any burrs on that surface. Ours is nice and clean. Now we'll make another pass with a clean paper towel and some brake cleaner to wipe off any dirt and debris that's still on that surface. If you're getting a lot of black coming up on the paper towel don't be afraid to do this a few times. The cleaner that surface is the better it's going to seal.

Here we have our old timing cover that we removed from our truck and our new part from 1AAuto.com. As you can see these parts are the same. The same face, same timing mark. You have a nice new front crank seal and crank position sensor location as well as all the same bolt locations. It even comes with some nice new hardware. This also comes with a crank position sensor block off plate as this is going to fit a lot of the older small block Chevys, which may have a non-computer controlled ignition system, meaning there would be no need for a crank position sensor, allowing you to just plug that off and bolt it on.

Back side also comes with some new gasket on it. We'll need to use some gasket sealer down here to seal it up against the oil pan. Other than that this part is one time use only so if you've removed your old one to do a timing chain or to get at anything else inside the motor, you'll need to replace it with this new part from 1A Auto, which is going to go in direct fit just like your original equipment and fix you up right.

There's no actual gasket in the bottom part here which sits into your oil pan, so we're going to go ahead and load that up with some oil safe gasket sealer. Don't worry too much about using too much here because we're going to go ahead and dump our oil and do an oil change after this process anyway. Make sure you get all the way over to the corners here so it'll seal off. This is time sensitive so make sure all of your bolts are pushed back or out if they're not going to fit and lay this into the engine. Set the bottom edge in and over the oil pan first. The rest will fall into place. We had our 10 millimeter socket and extension ready to go so we could start some bolts in. Most gasket sealers require a few minutes to set up so be sure to check the label on your particular gasket sealer before torquing the bolts to 18 foot pounds. Now there's no specific sequence for these but you should try to cross it up a little bit to make sure that you don't pinch one side down while leaving the other side loose. Install your crank position sensor and start the eight millimeter screw into the bottom of the timing cover by hand. We'll then tighten this down with an eight millimeter socket and ratchet. Once the bolt's tight, reconnect the electrical connector.

Install the appropriate installer tool into your crank shaft. Ours is 7/16 by 20 thread. You may need to use a pair of pliers to get that in nice and tight. Install your harmonic balancer onto the crank and give it a couple of taps with a hammer, just to get it started on there. You then install the sleeve of the installer tool, bearing, and the nut. You can then install the bolt. Now every tool is different, so use the appropriate size wrench to tighten the nut down until your harmonic balancer is bottomed out, and if necessary there's two flats on the tool here, so you can hold that with the wrench and prevent it from rotating. Once the harmonic balancer is bottomed out, you can back it off, remove the tool.

Reinstall the crank shaft pulley with the three 14 millimeter bolts. Tighten those down with the 14 millimeter socket, ratchet, and extension. Reinstall your 16 millimeter crank bolt and washer. For now, we'll just tighten down the crank bolt as much as we can with the 16 millimeter socket and ratchet. Once we get the belt on, we should have a little more leverage to torque it.

Clean the gasket services for both sides of the engine water pump. It's just these two little two-bolt flanges here. All we're going to do is just get in there with a razor blade. Scrape off any old gasket material, and then wipe it down with a rag or a paper towel and some brake cleaner.

Set your water pump bolts through and place the gaskets onto the bolts. This can get kind of tricky because you want to keep everything in place and get this inlet hose back on. It's much more difficult to do once it's on the vehicle. Slide the clamp back into place. Make sure your gaskets are still in place on the bolts then line up your water pump with a 14 millimeter socket and extension. Get your hardware started. Snug the bolts with a 14 millimeter socket, ratchet, and extension. Torque these bolts to 30 foot-pounds. Reinstall the remaining top hose and clamp as well as the bottom hose and that clamp.

Loop your serpentine belt under the crank pulley. We'll then go under the water pump, around the top, down and under the power steering pump, and over the A/C compressor pulley. On the left, we'll go over the tensioner and over the alternator. We'll then hold down where it will go below the idler pulley.

Using the drive from a 3/8 ratchet, we'll turn the tensioner counter clockwise. Slide the belt under. Take a quick look to make sure everything is aligned. There we go. Put tension back onto our belt. Using your ratchet, put tension on the serpentine belt by rotating the tensioner clockwise. Using your 16 millimeter socket, torque the crank bolt to 74 foot pounds.

Reinstall the clutch fan and just snug it up by tapping it on with a wrench.

Reinstall your upper radiator fan shroud. Reinstall the seven 10 millimeter bolts securing your fan shroud. Tighten them down with a 10 millimeter socket and ratchet. Reinstall the wire along the top of your shroud. Rock it back into place.

Fill your vehicle with a 50-50 mix of Dex-Cool coolant. We're using the special funnel to show you how much air actually comes out of the system when you do this, but any old funnel will do at home.

To finish bleeding your cooling system, simply leave the radiator cap off, start your vehicle, and set your defrosters or vents to the lowest fan speed and the highest temperature setting. This will allow the heater core to bleed as well. Just run the vehicle. Keep an eye on the temperature gauge. Let it get up to temp and monitor the coolant level inside of your radiator and top off as necessary. You'll notice that there will be several surges where it sort of burps and an air bubble comes out. It loses some fluid. You top it off and this process will probably repeat a few times.

Thanks for watching. Visit us at 1AAuto.com for quality auto parts, fast and free shipping, and the best customer service in the industry.
