How to Replace Windshield Wiper Switch 1995-2002 Honda Accord
Created on: 2010-09-23
Check out this video to learn how you can replace the windshield wiper switch on your 92-02 Honda Accord. 1A Auto experts will show you how!
-
step 1 :Disconnect the battery
- Use an 8 mm wrench to disconnect the negative battery terminal
-
step 2 :Remove the steering column trim
- There are three Phillips screws to remove.
-
step 3 :Remove the wiper switch
- Pry apart the two steering column trim pieces.
- Turn the wheel to access the two Phillips screws at the base of the wiper switch.
- Pry out the wiper switch by using a flat blade screwdriver to depress the tab.
- Unplug the wiring harness.
-
step 4 :install the new wiper switch
- Plug in the wiring harness and clip the switch down into the steering column.
- Secure with the two Phillips screws.
-
step 5 :Re-install the steering column trim
- Clip the two steering column trim pieces back on
- secure with the three Phillips screws.
- Reconnect the negative battery terminal with your 8 mm wrench.
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
8mm Wrench
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet. Hi, I'm Mike Green. I'm one of the owners of 1A Auto. I want to help you save time and money repairing and maintaining your vehicle. I'm going to use my 20-plus years experience restoring and repairing cars and trucks like this to show you the correct way to install parts from 1AAuto.com. The right parts, installed correctly--that's going to save you time and money. Thank you and enjoy the video.
In this video we are going to show you how to replace the wiper switch on this '95 Accord. Same as any '94 to '97. The only tools you'll need are a Phillips screwdriver and a small flat blade screwdriver. You're going to start by disconnecting your negative battery terminal. Remove three screws from the bottom that hold the steering column trim together. One is up in there. This is your adjust lever here. One is on the other side, right up there above where the key goes. One's down in the middle, right here. Those all three are Phillips screws. Once you have those screws removed, just pull this apart. This piece comes, the top comes right off. The bottom pulls out and down. Pretty easy process.
You're going to want to put your key on a little bit so you can turn the wheel and then get to these two Phillips screws and remove them. Once those screws are out, you just want to use a little screwdriver to pull out there. There's a little loop that holds it. This one looks like it's been replaced before and it's been broken. Pull it right out. Here's your switch. There's a lead right here with a delay. Here's the original one. Here's the new one from 1A Auto. You can see all the same. Everything's going to bolt up and hook up the same. All the same connections. Just the graphics a little fresher. This one is fine on this car, so installation... Hook our harnesses back up. Slide it into place. It will click and then put the screws back in. Installing this trim is easy enough. Put the top on, put the bottom on. Twist it a little bit. Snap it together. Now put the three screws back in. Now we'll speed up going through these screws. Then you're just going to want to reconnect your battery and you'll be all set.
We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
