1A Auto Video Library
Our how-to videos have helped repair over 100 million vehicles.
How to Replace License Plate Lenses Bulbs 2011-17 Toyota Camry
Created on: 2019-03-04
How to replace a broken, damaged or burned out license plate bulbon a 11, 12, 13, 14, 15, 16, 17, Toyota Camry.
-
step 1 :Removing the License Plate Lenses & Bulbs
- Use a trim tool to remove the 13 body trim clips from the felt trunk liner
- Remove the felt trunk liner
- Disconnect the bulb electrical connector
- Push the trunk tabs toward one another to push out the plate light assembly
- Grab the lens to pull out the light assembly
- Use a flat blade screw driver to remove the lens from the assembly
- Pull the bulb out from the connector
-
step 2 :Replacing the License Plate Lenses & Bulbs
- Replace the bulb with a new 194 bulb
- Replace the lens
- Line up and insert the light assembly and press the tabs inside the trunk to secure the assembly with a flat blade screwdriver if needed
- Reconnect the electrical connector
- Pull the emergency release through the opening in the liner
- Line up the felt trunk liner
- Replace the 13 body trim clips, starting with the center clip
Tools needed
-
Flat Blade Screwdriver
Trim Tool Set
